ADAS - RADAR

Automotive assistance systems require radar, lidar and opto-electronic sensors that must be robust, reliable and precise. One example of this technology are cameras with lenses that must be aligned perfectly over the sensor dies during their production.

One innovative solution for this process is the ASMPT Autopia. With its Active Alignment feature, it reads the image signal of the CMOS sensor and compares it with reference image values while it positions the lens. A placement solution like the SIPLACE CA (Chip Assembly) can combine sensors & bare dies with SMT components to form compact SiPs (systems-in-package).

SIPLACE CA

High Speed and Large Panel Die/SMD Bonding

  • Accuracy: +/- 10µm @ 3σ (local alignment)
  • Up to 685x650mm substrate handling
  • Combining Wafer, Tape&Reel and Trays in a single platform

Video More information

NEXX P300 (Stratus)

RDL and Cu-Pillar Deposition

  • Up to 30 plating positions and 6 chemistries
  • Advanced pre-wet and membrane cells
  • Flexibility in wafer thickness and warpage
  • 300/200mm bridge tool

Video More information

ALSI Laser1205

Mold Dicing

  • Narrow dicing width using multi beam (20um depending on filler size)
  • Ability to dice multi layer stacks (mold, Si, back Metal, Low-K)
  • Alignment capability for molded wafers (M-WLCSP)
  • Kerf check on the fly

More information

DEK Galaxy

Solder Ball Attachment

  • Highest print accuracy platform 2.0Cpk repeatability @ ± 12.5μm
  • High accuracy applications at wafer, substrate and board level
  • Fastest Printing platform at 7 sec

Download brochure
