Regensburg, August 14, 2025 – ASMPT will be present when the ECOC 2025 Exhibition, Europe’s leading trade fair for optical communication, opens its doors in Copenhagen from September 29 to October 1. At Booth 1131 in Hall C of the Bella Center, the global market and technology leader in hardware and software solutions for semiconductor and electronics production will present forward-looking technologies for silicon photonics and co-packaged optics (CPO). The premiere of the MEGA-P multi-chip bonder will be a special highlight at the ASMPT booth.
With its long-standing expertise in interconnect technologies and its deep understanding of the challenges in optoelectronics manufacturing, ASMPT provides powerful answers to the growing need for the efficient integration of optical components, especially with regard to applications like high-speed data transmission, data centers, and future AI infrastructures.
MEGA-P: High-precision multi-chip packaging in a single platform
At ECOC 2025, ASMPT will unveil its new MEGA-P platform, a versatile solution for the precise and efficient packaging of complex multi-chip modules in the areas of photonics, sensor technology, and optical communication.
Thanks to its modular architecture, the MEGA-P combines a broad range of processes in a single system, including the application of adhesives, 3D post-dispense inspection, and a “look-through” bond head for maximum precision and UV curing. This allows even complex designs to be implemented flexibly and efficiently, for example in applications that call for the integration of lenses or photonic components.
With its intelligent process architecture and integrated automation, the MEGA-P combines several previously separate machine functions while maintaining high precision and adaptability. Users benefit from faster setups, more throughput and maximum flexibility in the face of changing requirements.
“The complexity of modern semiconductors poses new challenges, particularly where bonding technology is concerned,” explains Dr. Johann Weinhändler, Regional Head ASMPT Semiconductor Solutions and CEO of ASMPT AMICRA. “With the MEGA-P platform we have created a solution for tasks that previously required a complete machine line while delivering maximum flexibility thanks to its modular design.”
Precise solutions for co-packaged optics
At the ASMPT booth, visitors can also learn about high-precision manufacturing solutions for co-packaged optics, including the AMICRA NANO and AMICRA NOVA Pro systems, each of which is tailored to different requirements in optoelectronics integration.
The AMICRA NANO is designed for the greatest placement accuracy, making it ideal for research, prototyping and complex development projects. It enables the reliable processing of the finest structures and supports modern hybrid bonding processes for applications like the precise integration of photonics and electronics in the smallest of spaces.
The AMICRA NOVA Pro is designed for volume-oriented production. It features high processing speeds paired with high precision, making it particularly suitable for advanced packaging applications. With its automation and flexible material processing capabilities, it makes the mass production of photonics more flexible and scalable.
The MEGA-P chip bonder features high flexibility and a modular design while taking up little space (2,550 × 2,085 × 1970 mm or 100.4 × 82 ×77.6 inches).
Image credit: ASMPT
The AMICRA NANO high-precision die and flip-chip bonder was specially designed for the production of co-packaged optics and features a placement accuracy of ±0.2 µm @ 3 σ. ± 0.2 μm at 3 σ.
The AMICRA NOVA Pro meets the growing demand for die-bond- and flip-chip-capable machines with high throughput (UPH1000) and maximum precision in the 1-micron range.
